| Machine Size |
1,780mm (W) x 1,300mm (D) x 1,210mm (H) [70" x 51" x 48"] with recommended stand |
| Machine Weight |
Approx. 165kg (364 lbs) including platen *not including stand |
| Platen Sizes |
Maximum Print Size is 406mm x 533mm (16" x 21") |
| Included Platen Size |
356mm x 406mm (14" x 16") |
| Ink Type |
Water-based pigment ink |
| Ink-Head Type |
Brother manufactured on demand piezo head |
| Number of Ink-Heads |
2 print heads / 8 ink channels |
| Print Resolution |
1200 dpi x 1200 dpi |
| Print Mode |
Single or double for CMYK. Underbase and highlight for white. |
| Environment |
Standby Conditions: 10°C - 35°C (50°F - 95°F), 20%-85% relative humidity Operating Conditions: 18°C - 30°C (64°F - 86°F), 35%-85% relative humidity |
| Data Output |
Printer driver (USB, File Output, LAN) |
| Power Supply |
AC 100V-240V, 50/60Hz ± 1Hz |
| Power Consumption |
1.6A(Average) [Reference: 0.8A - during circulation] |
| Ink Cure |
Heat press machine can be used at 180°C (356°F) - and 35 seconds duration. For higher volume production, a conveyor oven is recommended to be used at 160°C (320°F) for 3.5 minutes. Time and temperature may vary depending on which manufacturer's dryer is used. |
| Pre-Treatment |
Before printing, apply pre-treatment using either a manual or automatic device and then dry garment using a heat-press, being sure to follow all manufacturer's instructions. Pre-treatment is necessary for white ink. |
| Operating System |
Windows 8.1 [64bit], Windows 10 [64bit] macOS® 10.14 Mojave, macOS® 10.15 Catalina |
| Interface |
USB2.0, LAN [10 BASE-T, 100 BASE-TX, USB Flash Memory (Under 32GB, FAT32 format)] |
| Driver Operating |
2GHz CPU (minimum recommendation) |
| Conditions |
4GB RAM (minimum recommendation) |
| Display Resolution Recommended |
XGA (1024x768) (minimum recommendation) |
| Applications |
Adobe® Photoshop CS6/CC, Adobe® Illustrator CS6/CC, CorelDRAW® 2018/2019 (Windows) |
