Arlon

Arlon Premium Cast Vinyl with Low Profile X-Scape Technology

Arlon DPF 6100XLP is a premium 2-mil cast digital vinyl designed for high-quality vehicle, fleet and graphic applications.

View Specifications
Cast Vinyl Arlon Premium Cast Vinyl with Low Profile X-Scape Technology
2 years Shelf Life
50 micron Thickness
200% Avg. Elongation
70–90 Gloss Units Surface Finish
DPF 6100XLP is a 2-mil (50 micron) gloss white cast film with bubble releasing, tinted, clean removing, repositionable, permanent pressure-sensitive adhesive. The LX (Low Profile) X-Scape Technology® allows installers to achieve speedy installation while maintaining a high enough tack to ensure long-term bond. Designed for large format graphics, DPF 6100XLP is made of premium quality cast facestock with a low profile liner. The adhesive system is designed to provide excellent opacity as well as easy installation. The film provides superior conformability around rivets, curves, contours and channels. DPF 6100XLP is rated for outdoor durability up to 10 years (unprinted). Printed durability is dependent on the ink system used. Its Low Profile X-Scape Technology® helps create a smooth, paint-like appearance while allowing installers to achieve fast and efficient application. The film is compatible with Eco-Solvent, Solvent, UV and Latex printing technologies.
Key Features

Arlon Premium Cast Vinyl with Low Profile X-Scape Technology

Arlon DPF 6100XLP is a premium 2-mil cast digital vinyl designed for high-quality vehicle, fleet and graphic applications.

  • Digital printing with a wide variety of direct print systems
  • Vehicle graphics (full, partial), vehicle decals, fleet graphics, and wall graphics (interior) applications
  • Warrantied for use on rivets, corrugations and channel structures
  • Excellent opacity for vibrant graphics
  • Paired with Series 3170, Series 3200, Series 3210, Series 3220, Series 3270, or Series V3370 overlaminates for enhanced durability and finish.
  • Approved for deep channels
  • No primer required for the listed application
Arlon Premium Cast Vinyl with Low Profile X-Scape Technology — Key Features
Specifications

Technical Specifications

PROPERTY TEST METHODS TYPICAL VALUE
SURFACE FINISH Gloss Meter 60° Reflection 70 to 90 Gloss Units
THICKNESS Micrometer, Federal Bench Type 2-mil (50 micron)
TENSILE STRENGTH Tensile Tester with 2-in (51 mm) jaw separation; crosshead speed of 12 in/min. (5.1 mm/s), web direction ≥ 4.5 lb/in ≥ 0.8 kg/cm
ELONGATION Instron Tensile Tester as above Average 200%
SHELF LIFE (IN BOX) Ideal Storage Temperature 70°F (21°C) and 50% relative humidity 2 years from factory shipment
OPTIMAL APPLICATION
TEMPERATURE RANGE		 On clean, dry substrate 60°F to 80°F 16°C to 27°C
On clean, dry substrate (corrugated with rivets and channels) 60°F to 80°F 16°C to 27°C
SERVICE
TEMPERATURE RANGE		 On clean, dry substrate -40°F to 176°F -40°C to 80°C
DIMENSIONAL STABILITY 158°F (70°C), 48 hours 0.010 in 0.24 mm
PEEL ADHESION PSTC-1, 15 min, 70°F (21°C) ≥ 3.6 lbs/in ≥ 0.68 kg/cm
LINER RELEASE TLMI Release at 90°, 300 in/min (760 cm/min) 50 g/2 in 9.84 g/cm
Applications

Endless Possibilities

Arlon Premium Cast Vinyl with Low Profile X-Scape Technology is ideal for a wide range of materials and industries.

Damian-Tarczukowski

Damian-Tarczukowski

Werbetechnik-Thalhofer

Werbetechnik-Thalhofer

Wrap Design

Wrap Design
