| Product Model |
WallJet |
| Print Head Model |
EPSON I3200-U1 Made in Japan |
| Inkjet Method |
Drop-on-demand (DOD) |
| Nozzle Resolution |
720×600DPI, 720×1200DPI, 720×1800DPI, 720×2400DPI |
| Number of Print Head |
1 (Can be customized to customers needs with two print heads) |
| Ink Type |
UV INK |
| Ink Color |
CMYKW (Varnish function can be customized) |
| Ideal Operating Temperature Range |
5°C–35°C |
| Image Width |
Unlimited (can print as wall as length) |
| Image Height |
Default height 2700mm, customizable to up to 5000mm |
| Surface Tracking |
Ultrasonic sensors from Banner Technology to detect and adjust |
| Ink Curing System |
UV LED curing lamps with air cooling system and sensor control |
| RIP Software |
MainTop or FlexiPrint |
| RIP Software Language |
English, Portuguese, French, Italian, German, Spanish, Chinese, Japanese, Korean, Dutch, Danish, Finnish, Russian |
| Power Requirements |
100–240V AC 50–60HZ |
| Power Consumption |
Maximum power 350W, static power 100W |
| Operator Control Language |
English, Spanish, German, Italian, French, Russian, Dutch, Hindi, Portuguese, etc |
| Print Direction |
Bidirectional / Unidirectional |
| Horizontal Driving System (X-axis) |
Build in wheel and rail working as conditional use |
| Ink Tank Capacity |
CMYKW, 260ML for each color with ink alarm and stirring system |
| Printing Speed |
4–8 sqm/h as per resolution |
| System Platform |
WIN10, WIN11, MainTop/FlexiPrint, HKHR Control Software |
| Transmit Data |
Gigabit network |
| Laser Positioning |
Printing at any designated location with large image stitching |
| Image Blank-skip Technology |
Saves printing time for images with blank spaces |
| Mode of Transport |
Flight case |
| Print Log |
Check printing history |
| Unique Features |
Auto-cleaning and vacation mode maintenance |
| After-sales Support Language |
English, French, Polish, Russian and others |
| Machine Weight |
100KG |
| Machine Color |
Default black, customizable colors available |
| Features |
Customizable according to customer requirements |
| Origin |
China |
| Customized Aviation Crates |
Yes |
| Documentation |
Patent, CE, LVD, MD, Test reports as EU standards |
